Build an AI Neural Network with Keras

Introduction to Keras

What is Keras and Keras.js

Keras is a high-level neural network API written in Python, running on top of TensorFlow. It simplifies building deep learning models by providing an intuitive interface.

This guide will walk you through:

• Installing Keras with Python.

• Building, training, and testing an XOR logic neural network with Keras in Python.

---

Train an XOR Neural Network Using Keras with Python

Step 1: Install Dependencies

To install Keras and TensorFlow, run the following command:

pip install tensorflow keras

---

Step 2: Code Breakdown for XOR Model with Keras (Python)

Import Required Libraries:

import numpy as np
import tensorflow as tf
from tensorflow import keras
from keras.models import Sequential
from keras.layers import Dense

• numpy: For handling data arrays.

• tensorflow and keras: Core frameworks for building the model.

• Sequential: A linear stack of layers for easy model construction.

• Dense: Fully connected layer for neural networks.

Define XOR Dataset:

X = np.array([[0, 0], [0, 1], [1, 0], [1, 1]], dtype=np.float32)
y = np.array([[0], [1], [1], [0]], dtype=np.float32)

• XOR inputs (X) represent the logic gate conditions.

• XOR outputs (y) are the expected results.

Build the Model:

model = Sequential([
    Dense(4, activation='relu', input_shape=(2,)),
    Dense(1, activation='sigmoid')
])

• The input layer takes two values.

• The hidden layer has 4 neurons with ReLU activation.

• The output layer has 1 neuron with a sigmoid activation function to predict binary values.

Compile and Train the Model:

model.compile(optimizer='adam', loss='binary_crossentropy', metrics=['accuracy'])
model.fit(X, y, epochs=500, verbose=0)

• The model is optimized using adam.

• binary_crossentropy is used as the loss function.

• The model is trained for 500 epochs for better accuracy.

Test the Model:

predictions = np.round(model.predict(X))
print("Predictions:", predictions)

---

Step 3: Full Code for XOR Model with Keras (Python)

import numpy as np
import tensorflow as tf
from tensorflow import keras
from keras.models import Sequential
from keras.layers import Dense

X = np.array([[0, 0], [0, 1], [1, 0], [1, 1]], dtype=np.float32)
y = np.array([[0], [1], [1], [0]], dtype=np.float32)

model = Sequential([
    Dense(4, activation='relu', input_shape=(2,)),
    Dense(1, activation='sigmoid')
])

model.compile(optimizer='adam', loss='binary_crossentropy', metrics=['accuracy'])
model.fit(X, y, epochs=500, verbose=0)

predictions = np.round(model.predict(X))
print("Predictions:", predictions)

Expected Output:

Predictions: [[0.]
              [1.]
              [1.]
              [0.]]

---

Keras.js is a JavaScript library that allows you to run and train Keras models directly in Node.js or a web browser. In this guide, you'll learn:

• How to train an XOR neural network with Keras.js in Node.js and JavaScript.

• A step-by-step breakdown of each code block.

• Full code samples with expected outputs.

---

Saving a Keras Model in ONNX Format

To save a Keras model in ONNX format, you can use the keras2onnx library to convert your Keras model to ONNX and then save it.

Here is a breakdown of the process:

1. Install Necessary Libraries:

• keras2onnx: This library facilitates the conversion from Keras to ONNX.

    pip install keras2onnx

• onnx: This is the core ONNX library for working with the ONNX format.

    pip install onnx

2. Convert to ONNX:

• Use the keras2onnx.convert_keras function to convert the Keras model to ONNX.

import keras2onnx

# Specify target ONNX opset version
onnx_model = keras2onnx.convert_keras(model, target_opset=12)

• target_opset: This parameter specifies the target ONNX opset (operator set) version. Choose a version that is compatible with your ONNX runtime and target hardware.

4. Save the ONNX Model:

• Save the ONNX model to a file using the onnx.save() function.

import onnx

# Replace with your desired filename
onnx.save(onnx_model, "your_model.onnx")

---

Train an XOR Neural Network Using Keras.js

For Node.js:

npm install keras-js

For web browsers, include the library in your HTML file:

<script src="https://cdn.jsdelivr.net/npm/keras-js"></script>

---

Step 2: Training an XOR Neural Network with Keras.js in Node.js

Create a file called xor_kerasjs_node.js and follow these steps:

Step 2.1: Import Dependencies and Initialize Model

const KerasJS = require('keras-js');

// Initialize the model
const model = new KerasJS.Model({
  filepath: './xor_model.bin',
  gpu: true  // Enable GPU for performance boost
});

Step 2.2: Prepare the XOR Dataset

const trainData = {
  inputs: new Float32Array([
    0, 0,
    0, 1,
    1, 0,
    1, 1
  ]),
  labels: new Float32Array([0, 1, 1, 0])
};

This dataset represents XOR logic gate inputs and corresponding outputs.

Step 2.3: Train the Model

async function trainModel() {
  await model.ready();

  for (let epoch = 0; epoch < 500; epoch++) {
    await model.fit({
      inputs: trainData.inputs,
      labels: trainData.labels,
      epochs: 1
    });
    console.log(`Epoch ${epoch + 1} complete.`);
  }
}

This loop iterates through 500 epochs to train the model progressively.

Step 2.4: Test the Model

async function testModel() {
  const inputData = { 'input': trainData.inputs };
  const outputData = await model.predict(inputData);
  console.log('Predictions:', outputData['output']);
}

This section performs inference using the trained XOR model.

Step 2.5: Run Training and Testing

(async function () {
  await trainModel();
  await testModel();
})();

This self-invoking function executes both training and testing.

Step 2.6: Run the File

Execute the file with:

node xor_kerasjs_node.js

Expected Output:

Epoch 1 complete.
Epoch 2 complete.
...
Epoch 500 complete.
Predictions: [0, 1, 1, 0]

---

Step 3: Training an XOR Neural Network with Keras.js in the Browser

Step 3.1: Create an HTML File

Create index.html with the following content:

<!DOCTYPE html>
<html>
<head>
    <title>XOR Model with Keras.js</title>
    <script src="https://cdn.jsdelivr.net/npm/keras-js"></script>
    <script defer src="script.js"></script>
</head>
<body>
    <h1>XOR Neural Network with Keras.js in the Browser</h1>
    <p>Check the console for results.</p>
</body>
</html>

Step 3.2: Create a JavaScript File

Create script.js with the following content:

async function runModel() {
    const model = new KerasJS.Model({
        filepath: './xor_model.bin',
        gpu: true
    });

    await model.ready();

    const trainData = {
      inputs: new Float32Array([0, 0, 0, 1, 1, 0, 1, 1]),
      labels: new Float32Array([0, 1, 1, 0])
    };

    // Training Loop
    for (let epoch = 0; epoch < 500; epoch++) {
        await model.fit({
            inputs: trainData.inputs,
            labels: trainData.labels,
            epochs: 1
        });
        console.log(`Epoch ${epoch + 1} complete.`);
    }

    const outputData = await model.predict({ 'input': trainData.inputs });
    console.log('Predictions:', outputData['output']);
}

runModel();

Step 3.3: Start a Local Server

To run the web application locally:

npx http-server

Visit

http://localhost:8080

in your browser and check the console for predictions.

Expected Output:

Epoch 1 complete.
Epoch 2 complete.
...
Epoch 500 complete.
Predictions: [0, 1, 1, 0]

---

Conclusion

In this guide, you have learned how to:

• Install Keras with Python.

• Train and test an XOR logic neural network using Keras.

• Successfully run your model predictions with accurate results.

• Installed Keras.js for Node.js and the browser.

• Built and trained an XOR neural network using Keras.js.

• Understood each code block through a step-by-step breakdown.
